About RGB LED Light Strip

RGB Led Light Strip is a kind of the Multi-Color Changeable Led Strip , it need to work with the  RGB controller to realize RGB color changing.

RGB strips are capable of producing a wide range of color and when connected  to an RGB controller ,allow you  to select options such as the static color ,brightness or the color changing operating modes.

All of these options will allow a huge degree of control over what and how your LED's display their colors.

Note !

 The RGB color changing strip be able to produce multi RGB colors ,but only can mix to get pure white color . If you prefer to get RGB colors and Warm White ( or other kelvin White ) ,you can use the  RGBW / RGBWW LED Strips.

How to connect the RGB LED Light Strip to the RGB Controller

How the RGB LED Light Strip be cut and reconnected

RGB LED Lights Strip can be cut in every 3 leds (there is the marks on the PCB )

After being cutted ,the RGB LED Light Strip can be reconnected in two ways

*  By soldering wires to the marked solder points.

*  By using the Quick connectors.

   The quick connector can be  generally fall into three categories ：

         CC   (Connector to Connector)

         CWC  ( Connector  to Wire to Connector )

         CW ( Connector to Wire )

The connect drawing

* The connect drawing for  CC type quick connectors

* The connect drawing for  CWC type quick connectors

* The connect drawing for  CW type quick connectors

Notice: This quick connector is not water-proof !

so if you want to put the reconnected strip in outdoor environment ,  you need reconnect the strips as the follow process shows

*

About LightingWill

LightingWill is established since 2009. Professional LED manufacture, specially in LED lighting products and accessories. The objective of Lightingwill is to offer superior quality LED items to our clients, and enjoy a bright and comfortable life.

The recessed lights can be integrated into furniture or walls to create a warm and friendly atmosphere. Perfect for home use, office, store, super market, bars, cafe, exhibition, halls, museum hotel, restaurant, decoration lighting and other lighting.

We offer high quality LED products of our own and partners directly from manufacturer.

Contact info:

HUAKE LIMITED

Web: http://www.lightingwill.com

Email: [email protected]

Tel: +86-755-83066884

Fax: +86-755-83068542

Add: 1#, ChaXi SanWei Industrial Zone, GuShu, XiXiang, BaoAn，ShenZhen, GuangDong, 518126，China.

!!!!!Never disassemble the device without instructions! Never try to remove the TF card from the device! !!!!!

3D Holographic Display Instructions

1. Download the DSeeLab app and install it on your phone or pc.

For

iOS: Search DSeeLab in App store.

For Android: Click https://www.dseelab.com/resource/software to download.

For PC:https://www.dseelab.com/resource/software to download.

These only fit for LL-HA-50-WF-DS-X &LL-HA-50H-WFC-DS-X LL-HA-65-WF-DS-X & LL-HA-65X-WFC-DS-X & LL-HA-100-WFC-DS-X

Remark : Not fit for LL-HA-43-SDWF-FT-X & LL-HA-65X-SWF-ZB-X & LL-HA-100-SWF-ZB-X.

2. 2. Supply power to theDSeeLab Hologram Display Device
3. Open your phone, navigate to your phone's Settings->WiFi, you'll see there is a new WiFI source whose name starts with 'dsee'. Click it

to connect to it.

4. You will be asked to input a key. The 8-digit key could be found on the label at the back of your device.

5. After your phone is connected to the device, open the app on your phone, refresh the app.

6. Now you are all set!Only use the app to upload and manage videos and images.

You can also check our operation guide videos:

PC software operation video: https://www.youtube.com/watch?v=Jbd8PMn0xL8&t=25s

Cellphone (IOS and Android) APP software operation video: https://www.youtube.com/watch?v=0cSN3FYyWyM&t=19s

Remote operation video: https://www.youtube.com/watch?v=rmK0mDoyKec

1: We are manufacturer (https://lightingwill.com is offical online store of  HUAKE LIMITED), most prodcuts listed online are made by ourself (except some controller, power supplies from our partner). so we can offer a wide range of LED products.
For example, just for SMD3528-300 LED strips, there have 8 colors, and each color will have 4 waterproof versions, with 3 background color versions.  Total will have 8*4*3=96 different products, so for retailers no one can do such amount stock, but we can! we stock all necessary materials: different color LEDs, different background color PCBs etc. after get your order, we can produce the non-wateproof version within 1 working day, and wateproof version within 3 working days.

2: We cooperate with UPS, DHL, FedEx, TNT, USPS, HongKongPost to ensuring that your products will be shipped quickly and safely.

3: We provide a comprehensive after-sales service, check Reviews to see customer's comments on us.

4: We provide a flexible method of payment, such as credit card payment, Paypal online payment, T/T via bank transfer(HSBC) and Western Union

Beware of fake online stroe  (scam site)  who cribbing our photos, description etc,  we knew most of them are only few guys who copy our site, then buy garbage products from local market ship out to customer, the quality and services can not be ensured.

So, when you order online, if their site have same photos or same descriptions or when you checkout, if they only accept PAYPAL and Western Union, and if their PAYPAL's account are not compay account, then you need think about it.  if you need, please connect us, we will email you a scam site list.

As much as we google online for some info sometimes, it doesn't mean it would be equivalent with your effort like the words typing over the searching column, and most of description is written off the info statistics, hence, we get some trouble of finding the answer. It's obviously wanting to build up the entity of LED display system at first, like we all know signal of image or video carried by the digital medium and is sending out to the sending card as the first receiver, and actually it is the first receiving card instead of its name described here, because we need know this card will finish a job of signal collecting-up and encryption an so on, however, it's not difficult for us to get two things - how many of interface types will be available for input signal transform and what are numbers of them, seemingly the two factors will allow you to get if this card is supporting the sync, in addition, you will know your audio and video will be delivered at the same time rather than disorder of playing.

Counting to the next, you will access the real receiving card, loading ability, what sort of interface or ports it has, what kind of signal it will receive and recognize the signal, the other factor of card itself will be what sort of interface it has, and maximum LED module groups it can support, resolution ability, of course, the image quality or video presenting, like all general thing we know, the display quality will not be presented fine if the card is loaded too much, you can never expect that your production can work at peak all the time.

Controller, Video Processor, Video Production Console, these integrated devices are designed with high-end ICs and diversity of ports either related to input or output, apparently it will be capable of supporting a large program of LED display, that's why some special interfaces or rare types of ports for huge LED display screen are necessary to keep this system running well, and support more accessing ways for them to assemble as one part of the entire system, you have to know each point well before you want to build up the LED display screen, beware of roles they are acting and some critical parameters about card, processor, console and so on, as well as compatibility they are grouping up to display your ads to customer on the screen eventually.

LED Strip Light Photo Install Tutorial
Step one: Materials Needed
Have all your materials ready. You will need scissors, LED flexible strip lights, a solderless connector, ruler (if needed), and a set of hands.

Step Two: Measuring how many feet of LED strip you need
You may have your LED strip light sent to you in a reel (16 feet) or by the foot, depending on the quantity ordered. Decide how much flexible LED strip lighting you will need for your project. Since the LED strip can only be cut every third LED, you may have to go slightly over or under your desired specification.

Step Three: How to cut the LED strip
As you can see below, the flexible strip light can only be cut along the designated lines. Take a sharp pair of scissors and cut along the line.

Step Four: Pay attention to positive and negative markings
IMPORTANT: Notice the positive and negative sides of the LED strip light. This is important for the next few steps. Sometimes when you cut the LED strip light , things can get mixed around.

Step Five:  Introduction to the solderless connector
Each Solderless Connector has two sides. To insure you have the correct side up, make sure the wider of the white sides face up. This is the top.
BE GENTLE and pull the locking device out away from the wires. Do not pull on the wires to do so, as the solderless connector is fragile.

Step Six: Attaching the solderless connector to the LED strip
IMPORTANT: Color does not always matter! Make sure you follow the positive side of the flex strip down through the solderless connector wire to the power supply. Red/black can either mean (+) or (-) depending on what side you have hooked the connector to.

Step Seven: Securing the tray to the LED light
In the example below, if we were to attach the Solderless Connector to the other side of the flexible strip light, the red would be negative and the black positive.
Next, GENTLY secure the locking tray back in place, connecting the terminals of the LED flexible strip light to the connector. Be gentle and make sure the mounting tray is securely closed, or the lights will not work.

Step Eight: Connecting the LED strip to power
You are now ready to plug in your LED Flexible strip light to the LED power supply.
This can be done a few ways.

1. Wire Nuts

2. Butt Splices

3. Terminal blocks

4. DC Coaxial Connectors with or without screw terminals

Match the positive and negative markings with the positive and negative wires from the power supply. Make sure the power is off when you do this.

How to Start Your Own LED Display Screen Assembly Line？

The answer is DON'T think it too complicated and plan big at first.

First, to have a quick lesson on LED light display screen, let you have a clear picture.

There is 7 factors you need to consider for making a LED light display screen.

* LEDs

* LED Display Modules

* Cabinet

* Control System ( controller box, sending card & receiving card)

* Power Supply

* Data Cable & Power Cable

* Other device/tool need for local assembly

1. The LED Components

The LED light display screen has indoor and outdoor application. Beside the waterproof IP grade, the brightness required for Indoor and Outdoor application are different.

The outdoor LED light display screen need higher brightness than indoor LED light display screen, for it's disclosed under sunshine.

So for the LED components used, according to the brightness level are divided into for regular brightness (800-1000 nits) indoor LEDs and high brightness (4000 - 6000 nits) outdoor LEDs.

And the SIZE of the LEDs limit Pixel Pitch can make for indoor and outdoor LED light display screen.

The smallest indoor LED 0808 allow to make the smallest pixel pitch P1.0 Indoor LED display screen， while there are P1.25, P1.56, P1.667, P1.875, P1.923, P2, P2.5, P3, P4, P5, P6.

The smallest outdoor LED 1921 allow to make the smallest pixel pitch P3.0 Outdoor LED display screen, while there are P4, P5, P6，P6.7, P8, P10.

2. LED Display Modules

For the Modules, points to consider:

* Indoor LED modules and Outdoor LED modules :

Indoor LED Display Modules made with regular brightness LED, there are P1.0, P1.25, P1.56, P1.667, P1.875, P1.923, P2, P2.5, P3, P4, P5, P6 LED Display Screen Modules.

while Outdoor LED Display Modules made with high brightness LED, there are P3.0, P4, P5, P6，P6.7, P8, P10 LED Display Screen Modules.

* The Size of the LED Modules

You need to consider and well-known for the sizes of the LED display screen modules, to calculate the QTY. of LED display screen modules need for LED display screen / wall in different sizes.

And to know for a the same size LED display screen,  different Pixel Pitch LED modules used, the PRICES vary quite a lot.

Below is an example to show you. CLICK HERE TO KNOW WHY THERE ARE SO BIG DIFFERENCE.

3. The Cabinets

Two options: Die-casting Aluminum Cabinet and Standard Iron Sheet Simple Cabinet.

1) Die-casting Aluminum Cabinet: Need mold, is extruded to form via Molding Machine, and it has features as " High Quality Aluminum Alloy with Good Dissipation, High Brightness, High Grey Scale, Seamless Assembly, Silent Design with Fan-less Design".

2) Iron Sheet Standard Cabinet: Simple made, and can custom-make to any sizes. Note: customized size need to match with the LED display screen modules. Features: Light Weight, Independent disassembly box, High Brightness, High Grey Scale, Cabinet Size and Shape can be Customized Freely.

4. Control System (controller box, sending card & receiving card)

* The brands of controller/card depends on the customer preferences. If no special requirement, we will recommend the most cost-efficient model to our clients.

* The controlling pixel pitch qty. of those devices.

Each model of the controller/card has its max loading pixel pitch quantity (LED quantity).  We learn before that the different pixel pitch LED display modules vary a lot.

How many control card need for a LED display screen depends on the Pixel Density and the control card's spec.

The control card's Loading Capacity should bigger than the Pixel Density of your LED display screen.

Below picture show the Pixel Density for different LED Display Modules.

Below picture shows the Loading Capacity of different control card.

5. Power Supply

For the installation space is narrow, the power supply used for LED display screen should be small and in low profile.

QTY. need for different project, we can give your calculation.

* CE approved or UL approved

* Famous brand or common brand

6. Data Cable & Power Cable

We will give you the QTY. of each cable need, once get known of your projects.

7. Other device/tool need for local assembly

* Tools: Screw Driver, Multi-meter

* Aging test mounting bracket for LED display screen modules, we can give you solution for what we use in our own factory.

* Finished LED Display Screen Cabinet AgingTest Frame , we can give you solution for what we use in our own factory.

* Training ( assembly operator and software knowledge, we can provide the training).

Difference among SMD2835, SMD3528, SMD5050, SMD5630, SMD5730(SMD5630)

First, let me have a short look for different SMD LED the component. Below are some of the LEDs that are commonly used in LED Strip Lights.

The popular spec. for them we used in our strips:

SMD3528  (rated 0.06W/LED)

SMD2835  (rated 0.2W/LED)

SMD5050  (rated 0.2W/LED)

SMD5730/5630  (rated 0.5W/LED)

SMD3014 (rated 0.1W/LED)

SMD4014 (rated 0.2W/LED)

SMD3030 (rated 1W/LED)

SMD5050 RGB (rated 0.2W/LED)

SMD5050 RGBW (rated 0.2W/LED)

SMD5050 Dual White (rated 0.2W/LED)

The popular LED Flexible Strip models:

2, LED display module brightness level When it comes to brightness, we think of the word high brightness, this parameter is a parameter that people pay more attention to. Brightness is a complicated problem in LEDs. The brightness we usually say in LED modules is usually the intensity and transparency of the LEDs, which is usually the sum of the degrees associated with each module.

3, the LED display module illumination angle of view The illumination angle of the LED module without lens is mainly determined by the LED lamp bead. The different illumination angles of the LED lamp bead are also different. Generally, the illumination angle of the LED lamp bead provided by the manufacturer is the LED mode. The angle of the group.

4, LED display module working temperature LED display module normal working temperature is usually between -18 ° C and 58 ° C, if the requirements are relatively high, special treatment, such as air conditioning or exhaust fan.

LED bar screen is led light sticking on acrylic board, it needs to attach to glass, so led lamp heat dissipation is hindered. The new transparent LED screen adopts GOB manufacturing technology, breaking the defect of LED bar screen, making the transparent LED screen realize the characteristics of real moisture-proof, waterproof, dust-proof and UV-resistant so that the transparent LED screen can be used in any harsh outdoor environment.

The conventional LED screen	Transparent LED Screen Display

Firstly, you need to confirm the 3D hologram fan version you have, because there are several different versions, is it wifi&SD card version or just wifi version, or wifi & cloud version etc.

LL-HA-50-WF-DS-X &LL-HA-50H-WFC-DS-X LL-HA-65-WF-DS-X & LL-HA-65X-WFC-DS-X & LL-HA-100-WFC-DS-X  please download the app from https://www.dseelab.com/resource/software

Remark : Not fit for LL-HA-43-SDWF-FT-X & LL-HA-65X-SWF-ZB-X & LL-HA-100-SWF-ZB-X.

42cm is the SD card version. It is downloading the required material directly to the SD card and then use the controller to control the playback.

2, dispensing: it is to drop the glue to the fixed position of the PCB, its main role is to fix the components to the PCB. The equipment used is a dispenser, located at the forefront of the SMT line or behind the inspection equipment.

3. Mounting: Its function is to accurately mount the surface-assembled components to the fixed position of the PCB. The equipment used is a placement machine located behind the screen printing machine in the SMT production line.

4. Curing: The function is to melt the patch glue, so that the surface-assembled components and the PCB board are firmly bonded together. The equipment used is a curing oven located behind the placement machine in the SMT line.

5, SPI: After the printing machine, for the quality inspection of solder printing and verification and control of the printing process.

6. Reflow soldering: Its function is to melt the solder paste, so that the surface-assembled components and the PCB board are firmly bonded together. The equipment used is a reflow oven located behind the placement machine in the SMT line.

7. Cleaning: The function is to remove the welding residue (such as flux) which is harmful to the human body on the assembled PCB board. The equipment used is a washing machine, the position can be fixed, it can be online or not.

8. Inspection: The function is to test the quality and assembly quality of the assembled PCB. The equipment used includes a magnifying glass, a microscope, an on-line tester (ICT), a flying probe tester, an automatic optical inspection (AOI), an X-RAY inspection system, and a function tester. The position can be configured in a suitable place on the production line according to the needs of the inspection.

9, repair: its role is to detect the failure of the PCB board rework. The tools used are soldering irons, rework stations, and the like. Configure anywhere in the production line.

The 3D holographic LED fan product itself can identify many kinds of formats: JPG, GIF, MP4, avi, RMVB, MPEG, and these are not traditional 3D formats, so you need to make a corresponding video or picture format that you need to display the 3D effect. The current mainstream 3D software can do this, and this is a very simple operation for a person who is very unfamiliar with the 3D MAX software. And you just need to import these formats into the phone APP, computer software or the cloud platform we provide, directly import or release, is not very simple. Of course, if you don't quite understand it, we also have the corresponding video of each machine.

How do you measure the good or bad of a 3D holographic fan? Because we know his core logic. Then the processing speed of CPU, the resolution of imaging and the luminance produced are the most important factors to measure the product. In addition, the difficulty of the operation of the product also determines the popularity of the product. For example, SD card single version, WiFi version, cloud control version.

Although the 3D holographic LED fan is similar to the fan, it does not produce wind. His core principle is to image, video, or picture materials through the rotation of the luminescent LED lamp, decomposed into a realistic lattice by software processing, and then turn the dot matrix into visible video and pictures through the rotation of the LED. Generally speaking, people prefer to see his 3D effect in the air. Similar to holographic imaging, more people would prefer to call this product a 3D holographic LED fan.

According to the actual area of the product and the length and brightness of the fan blade, it is divided into many styles and specifications, but the essence is the same. The creative materials and contents to be played are stored through different paths and transmission methods. In the storage space of the machine itself. Through the software to process the video and image dot matrix to achieve the desired holographic effect

Patented GOB technology can effectively protect the LED packaging unit, which is enough to resist extreme harsh use environment, realize real waterproof, dust-proof, anti-impact, anti-UV, and can avoid the phenomenon of light drops.

1、Plug lights: Insert the different colors of the diode into the PCB plate hole, forming the LED pixel point. Often said that the pixel spacing is the distance between the two lamps, resolution is the amount of light in per unit area. Note: A. the direction of light, positive and negative pole not inserted opposite B. Don't plug the light less insert, wrong insertion C. check the diode itself has no problem D. QC detection
2、Solder:  A: machine over tin; B: Check out the lights to see if there is omission C: Cutting angle D: put down the middle of the individual light (easy to welded the behind drive plate)
3、Installation the LED module(1) the installation of the plastic frame; A. cutting the board B. Will do a good job of the lamp panel and frame locked C. Lay the screws
(2) The driver board A. SMT patches B. Drive cable joint; C: Power contacts Weld; D: welding the head of Capacitor; E: welding the U line and V line.

What is a pixel? How to define it?

Generally a pixel can be rendered as a unit of displaying pictures or videos in front of viewers. or actually the smallest element for picture, if we need more pictures, that means more original representations will be necessary part, all of these small dots will make up the final display, and you must be in doubt that why you are going to define a pixel as a picture, because the pixel can be one color at one time, and also is too small to be seen individually, and next we are going to give you the second question.

How many pixels of a image will be able to be seen clearly rather than in foggy dots? Each pixel can be determined by the number of colors in which all bits of dots blending together to represent it, for example, for various aspects, you need to know how many of pixels to be displayed in a image as we called pixel density, at 16-bit color depth, you may be able to see 'Led-Lights' not in a smooth, clear picture, what else if we set at 32-bit color depth? Unless you have your pixel density setting at a higher level, you will not get the best quality at 16-bit approach.

The more bits per pixel (bpp) you have described for a picture, the more excellent representation it can be able to produce. Learn about the pixel basics, to know the array of pixels make up of LED display, pixel pitch, lighting brightness or in poor brightness, optimal viewing distance, for such issues the explanation of what a pixel is and maximizing your comfort of viewing. Anyway, the article about the pixel is not described in details as you can expect, and we are going to make some fix at a time and we hope it may be able to tell some points already, some pics are quoted from web, if violated to your property, contact with us directly!

Content for electronic display should be balanced. It should not be so complex or so creative that it drowns out the brand altogether, on the other hand, it must not appear so simple that it is devoid of all sophistication. The answer lies in content being created that lies somewhere between complexity and simplicity. Finding the right balance is key.

There must always be content on LED screens which is useful in some way, arouses curiosity, and is fresh and updated. When content is updated constantly, people will tend to look at the screens more often. If the outdoor screen runs only advertisements, the target audience will quickly tire of it and may cease looking at the screen. It is a good idea to incorporate stock-exchange updates, the news, sports and the weather forecast into the programming, so that there is constantly some fresh content to look at. Even displaying updated temperature, a fact of the day or quote of the day will get people curious about what the next display is going to be about. In all probability, if your content is strong enough or thought-proving enough, people will begin commenting about your content and will be looking forward to the next update. This serves the purpose of advertising, which is to have as many people as possible look at your screen.

Another important point is to pay attention to is design. To begin with, ensure that you have a good advertisement designer who knows what he is doing. He should have some experience at designing, and should know instinctively what will work on digital signage. You should also encourage your designer to look at the advertisements as they appear on your screen, so that she will have a good idea about how the viewer will perceive it.

Duration of the advertisement is another factor to be borne in mind. Ideally, advertisements should not be so long that people will see the beginning but not the end as they move past. For outdoor screens, duration should be limited to a maximum of 10 to 15 seconds. Advertisements being broadcast indoors, where people may have more time to view them may extend a little bit more than this.

Finally, ensure that the format of the letters used is big. Each letter being a quarter of the screen size is most probably a good idea. Don’t make the mistake of thinking that what looks good on your computer will look good on your LED screen.
